V8 4.8-35×60 Mil-Dot Reticle (#43)

$3,999.99

Available on backorder

SKU: 522141 9943 040 - 1 Categories: , , , Tag:

V8 4.8-35×60 Mil-Dot Reticle (#43)

Ext. Elevation Turret, w/BDC (ASV) w/ ballistic rings – .33 MOA – Parallax Adj.

Equipped for everyday hunting: ZEISS V8 4.8-35×60 Mil-Dot Reticle (#43) riflescopes deliver more successful moments on the hunt than any other riflescope from ZEISS thanks to the combination of sophisticated features and their perfect interaction. Outstanding optical quality, an extra-large eye box for fast target acquisition, and the finest illuminated dot in the world make it an unsurpassed companion in any hunting situation. For greater success during your hunt.

Maximum sharpness, even at maximum magnification: thanks to the 35x magnification in combination with the optional bullet drop compensation, the ZEISS V8 4.8-35×60 offers the ultimate in long-distance shooting performance, enabling hunters to take precise shots from the greatest possible distance. For greater success when hunting at long distances.



V8 4.8-35×60 Mil-Dot Reticle (#43) Features

Advanced long-range bullet drop compensation

With an elevation adjustment range of up to 140 cm, and a click value of 1cm/100m per click, the bullet drop compensation ASV-Advanced Long Range (ASV-ALR) allows for precise sight corrections for precise shot placement at long-range.

35x Magnification

The 35x magnification combined with the bullet drop compensation (ASV) stands for ultimate long-range shooting capability – and success. The riflescope provides consistently excellent image sharpness while yielding the highest resolution of details from minimum to maximum magnification settings. This allows for utter-most reliable target identification, shot confirmation, and ultra-precise shooting over the longest distances.

The world’s finest illuminated dot

The secret behind the precision of ZEISS riflescopes is their ultra-fine illuminated dot and its extremely low target coverage. With only a fraction of the thickness of a human hair, the fibre optics system delivers the world’s finest illuminated dot – 3.3-millimetre target coverage at 100 metres is the breathtaking result (V8 & V6 @20x). Pure precision for the smallest targets and the greatest distances.

Brilliant image quality

The Ultra-FL Concept contains several SCHOTT fluoride glass elements for absolute color fidelity, brightness, and clarity. Ensuring you the finest resolution of details, even in the harshest conditions and most challenging environment.

ZEISS T* Coating

ZEISS T* coating is a guarantee of the brilliant, high-contrast images­­ which you will experience above all in adverse light conditions and in the twilight. Behind it, however, there is no specific formula for building up the layers. Instead, it is a technology that is constantly adjusted to suit new glass materials and requirements, which varies from lens to lens.

A clear view, whatever the weather

There are always exciting things to be seen in the world of nature – even in wet weather. This is why ZEISS developed LotuTec. A coating for the lenses of binoculars and spotting scopes that enables a clear and unhindered view in all weather conditions.

Stable and Shot-Proof

The ZEISS V8, ZEISS Victory HT, ZEISS Conquest V6, and ZEISS Conquest V4 riflescopes are all ideally suited for use with “clip-on” attachments.

Multifunction Button

The multifunction illumination control button is the most advanced reticle illumination system on the market. It can be quickly, silently, and intuitively operated even with gloves on. The illumination is automatically deactivated as soon as you put the weapon down. It reactivates as soon as you take aim, a feature that saves time and energy – and ensures an immediate and perfect aiming solution in any lighting condition.

The most versatile riflescope

The combination of maximum zoom range, the brightest optics and optimal ease of use makes the ZEISS V8 the ultimate all-purpose riflescope for all distances and situations – whether you are on a driven hunt, stalking, high seat hunting, or shooting at long-range. Whatever your hunting venture, the ZEISS V8 – the company’s best super-zoom riflescope – enables fast reactions and maximum flexibility. Designed to ensure maximum hunting success.

V8 4.8-35×60 Mil-Dot Reticle (#43) Specs

Performance

Magnification 4.8 – 35 ×
Effective lens diameter 48.1 – 60 mm
Light transmission 92%
Exit pupil diameter 9.9 – 1.7 mm
Twilight factor 13.6 – 45.8
Field of view at 100 m (yds) 8.6 – 1.2 m (26 – 4 ft)
Objective viewing angle 4.9° – 0.7°
Diopter adjustment range − 3.5 | + 2 dpt
Eye relief 92 mm (3.6 “)
Parallax setting 50 m – ∞ (54 yds – ∞)
Vertical adjustment range at 100 m 140 cm
Lateral adjustment range at 100 m 85 cm
Adjustment per click at 100 m 1 cm
Centre tube diameter 34 mm
Eyepiece tube diameter 46 mm
Objective tube diameter 67 mm

Features

LotuTec | Nitrogen filled + | +
Water resistance 400 mbar

Physical

Operating temperature − 25°C | + 50°C (− 13°F | + 122°F)
Length 399 mm (15.7 “)
Weight (without inner rail) 995 g (35.1 oz)
Weight (with inner rail) 1015 g (35.8 oz)

V8 4.8-35×60 Mil-Dot Reticle (#43) Reticle

Reticle 43 Illuminated

Our classic reticle for fast, long shots combined with the finest illuminated dot. At the respective riflescope’s reference magnification, the reticle’s characteristic dots are exactly 10 cm apart at a distance of 100 m, making it easy to accurately estimate distances. The angle between the dots at this magnification is exactly 1 millirad, allowing trained shooters to quickly determine the appropriate holdover point at long distances. The reticle is located in the riflescope’s second image plane. The ZEISS Hunting app can be used to quickly and precisely determine the change in subtension and the resulting bullet drop compensation and wind drift correction values for practically any ammunition.

Reticle Datasheet

Find the rest of our Zeiss Optics here

Weight 70 oz
Dimensions 14 × 4 × 4 in
